说明

由于部分内容涉及公司机密，已用字母替换，不影响阅读

实际效果

• 验证 1000 个接口平均耗时 6s（看机器配置及网速）
• 第一次投入使用，马上发现 5 个接口异常并且该验证过程不到 30s 的时间

框架的下一步

• 目前已兼容我们公司所有 app

• response body 全字段验证（含字段类型）

  • 已有思路

• 字段变化导致 2 个大问题

  • 由原本 int（0/1）变成了布尔型
  • 时间戳长度由 10 位突然变成 13 位

• 尽量避免日常监控中跑接口对外网数据/用户的影响

  • 目前做法是屏蔽相关接口
  • 目前状态
  • 跑接口时创建的数据 id 有变化，然而删除接口还是调用老的 id 去删除，导致数据删除不到
  • 改进
  • 拦截创建数据的 response body 取出对于 id
  • 拦截删除接口 request body，传入上一步拦截的 id

最新框架图（红色部分未完成）

部分代码

配置文件

http接口测试框架配置信息

tester = tester
project = A
versionName = 2.2.2
versionCode = 237
host = a-webapi.test.b.com
getTokenHost = http://a-webapi.test.b.com/api/System/GetToken
loginHost = http://a-webapi.test.b.com/api/User/LoginV2
loginInfo = Phone=13750199962&Password=FGgIwe5oCdk%3D
SessionsPath = D:\Fiddler Sessions
ApiURL = http://apihelper.b.com/Home/API/c
# SpecialSessions >> 屏蔽的接口
SpecialSessions = ['GetToken', 'LoginV2', 'LogOut', 'BookingV2']

启动测试入口

"""
运行api测试总入口
"""

import sessions.Request


def launcher_api_test():
    """
    1.获取接口列表
    2.与本地sessions对比
    3.差异化文件，是否继续
    3.1否 继续录制接口
    3.2是 开始跑接口
    :return:
    """
    r = sessions.Request.Request(0)  # 0 >> A    1 >> B
    r.start()


if __name__ == "__main__":
    launcher_api_test()

头部、登录接口

def __get_token_header(self):
    """
    生成token头部
    :return:
    """
    des = self.__get_token_des()
    arr = (des, self.conf['systemType'], self.conf['Model'], self.conf['Release'], self.conf['DeviceId'],
           self.conf['versionCode'], self.conf['versionName'], self.conf['AppBuild'], self.conf['DeviceOS'], "0")
    authorization = self.AUTHORIZATION_TOKEN % arr
    headers = {'Content-Type': 'application/x-www-form-urlencoded; charset=utf-8', 'Authorization': authorization}
    response = self.session.post(self.conf['getTokenHost'], headers=headers)
    if json.loads(response.text)['StatsCode'] == 200:
        data1 = json.loads(response.text)['Data']
        self.time = data1['Time']
        self.TOKEN_NAME = data1['TokenName']
        self.TOKEN_VALUE = data1['TokenValue']
    else:
        print("GetToken失败，请手动检查")
        utils.HandleJson.HandleJson.print_json(response.text)

def __login_session(self):
    """
    调用登录接口，这样后面的接口都能正常访问了
    :return:
    """
    url_login = self.conf['loginHost']
    headers = self.__get_session_header(url_login.split('api/')[-1])
    data_login = r'%s' % self.conf['loginInfo']
    response = self.session.post(url_login, headers=headers, data=data_login)
    if json.loads(response.text)['StatsCode'] == 200:
        data1 = json.loads(response.text)['Data']
        self.uId = data1[self.head_uid]
        self.uName = data1['NickName']
        self.uPhone = data1['Phone']
        self.SessionId = data1['Sid']
        self.uType = data1['UserType']
        self.uuid = data1['UID']
    else:
        print("登录失败，请手动检查")
        utils.HandleJson.HandleJson.print_json(response.text)

接口片段

Request url: a-webapi.test.b.com/api/Circle/AddCancelCollectCircle
Request header: POST /api/Circle/AddCancelCollectCircle HTTP/1.1
Host: a-webapi.test.b.com
Accept: text/json
Authorization: Digest t="2016-08-04 16:41:19",SystemType="2",u="Circle/AddCancelCollectCircle",r="59e93eb1a6625adc6bff5ede5945a2f7",DeviceId="ffffffff-8416-49fe-3fdc-6ee400000000",Model="SM-N9100",DeviceOS="22",Release="5.1.1",VersionName="2.2.2",VersionCode="239",PushToken="",uId="3353",uName="123456ejz",uPhone="13750199962",SessionId="%2FZhckUf9%2Fd2soQZhYofjN021SdWUpLv0aW%2F3CJBr71vtOl1YHJda6J8p6P1hsQS0P3kqirm%2BtPs%3D",uType="1",bDChannelId="",bDUserId="",AppBuild="239",uUID="2255"
Content-Type: application/x-www-form-urlencoded; charset=utf-8
Content-Length: 21
Connection: Keep-Alive
Accept-Encoding: gzip
User-Agent: okhttp/3.0.1

Request body: CircleId=6418&IsAdd=1
Response code: 200
Response body: {"StatsCode":200,"Message":"收藏成功","Data":null,"Other":null}
Session end



Request url: a-webapi.test.b.com/api/Circle/AddCancelCollectCircle
Request header: POST /api/Circle/AddCancelCollectCircle HTTP/1.1
Host: a-webapi.test.b.com
Accept: text/json
Authorization: Digest t="2016-08-04 16:41:22",SystemType="2",u="Circle/AddCancelCollectCircle",r="26dcb55ee9ac79995c21656517c455e8",DeviceId="ffffffff-8416-49fe-3fdc-6ee400000000",Model="SM-N9100",DeviceOS="22",Release="5.1.1",VersionName="2.2.2",VersionCode="239",PushToken="",uId="3353",uName="123456ejz",uPhone="13750199962",SessionId="%2FZhckUf9%2Fd2soQZhYofjN021SdWUpLv0aW%2F3CJBr71vtOl1YHJda6J8p6P1hsQS0P3kqirm%2BtPs%3D",uType="1",bDChannelId="",bDUserId="",AppBuild="239",uUID="2255"
Content-Type: application/x-www-form-urlencoded; charset=utf-8
Content-Length: 21
Connection: Keep-Alive
Accept-Encoding: gzip
User-Agent: okhttp/3.0.1

Request body: CircleId=6418&IsAdd=0
Response code: 200
Response body: {"StatsCode":200,"Message":"取消收藏成功","Data":null,"Other":null}
Session end

接口列表

你需要做的

• 环境配置

  • Python 3.x
  • fiddler 一枚（配置抓取手机请求）
  • PyCharm

• token/session 替换

  • 替换成你们项目对应的 token 等
  • 修改配置文件
  • 修改 response body json 判断逻辑

• 替换 fiddler js

  • 项目根目录的 fiddler js 整个文件内容替换 fiddler 的 js
  • 打开 fiddler 的 Customize Rules 功能
  • 删除所有内容，并把 fiddler js 内容全部拷贝进去
  • 修改拦截的 host 等信息
  • fiddler 保存请求

fiddler js 自定义信息

//自定义参数设置
public static var filterUrl = "a-webapi.test.b.com";
public static var filePath = "D:\\Fiddler Sessions\\Api\\";
public static var filePathForRequested = "D:\\Fiddler Sessions\\Requested.txt";
public static var filePathForErrorResponse = "D:\\Fiddler Sessions\\ErrorResponse.txt";
public static var filePathForVerifyRequset = "D:\\Fiddler Sessions\\VerifyRequset.txt";
public static var filePathForRemoveSession = "D:\\Fiddler Sessions\\RemoveSession.txt";
public static var filePathForAddSession = "D:\\Fiddler Sessions\\AddSession.txt";

• github 拉取代码
• 欢迎一起交流
