问答 ant+jmeter 用 jmeter-results-detail-report_21.xsl 输出 html 聚合报告结果，其中 summary 中的 90%Line，95%Line，99%Line，与.jtl 文件的结果不一致?
ant+jmeter 用 jmeter-results-detail-report_21.xsl 输出 html 聚合报告结果，其中 summary 中的 90%Line，95%Line，99%Line，与.jtl 文件的结果不一致
其中 jmeter-results-detail-report_21.xsl 的 90%Line，95%Line，99%Line 的计算方式主要代码为：
<xsl:template name="summary">
<h2>Summary</h2>
<table align="center" class="details" border="0" cellpadding="5" cellspacing="2" width="95%">
<tr valign="top">
<th># Samples</th>
<th>Failures</th>
<th>Success Rate</th>
<th>Average Time</th>
<th>Min Time</th>
<th>Max Time</th>
<th>Median</th>
<th>90% Line</th>
<th>95% Line</th>
<th>99% Line</th>
<th>QPS</th>
<th>KB/Sec</th>
</tr>
<tr valign="top">
<xsl:variable name="allCount" select="count(/testResults/*)" />
<xsl:variable name="allFailureCount" select="count(/testResults/*[attribute::s='false'])" />
<xsl:variable name="allSuccessCount" select="count(/testResults/*[attribute::s='true'])" />
<xsl:variable name="allSuccessPercent" select="$allSuccessCount div $allCount" />
<xsl:variable name="allTotalTime" select="sum(/testResults/*/@t)" />
<xsl:variable name="allAverageTime" select="$allTotalTime div $allCount" />
<xsl:variable name="allMinTime">
<xsl:call-template name="min">
<xsl:with-param name="nodes" select="/testResults/*/@t" />
</xsl:call-template>
</xsl:variable>
<xsl:variable name="allMaxTime">
<xsl:call-template name="max">
<xsl:with-param name="nodes" select="/testResults/*/@t" />
</xsl:call-template>
</xsl:variable>
<xsl:variable name="allMedianLineTime">
<xsl:call-template name="line">
<xsl:with-param name="nodes" select="/testResults/*/@t" />
<xsl:with-param name="position" select="ceiling($allCount * 0.5)" />
</xsl:call-template>
</xsl:variable>
<xsl:variable name="allNinetyLineTime">
<xsl:call-template name="line">
<xsl:with-param name="nodes" select="/testResults/*/@t" />
<xsl:with-param name="position" select="ceiling($allCount * 0.9)" />
</xsl:call-template>
</xsl:variable>
<xsl:variable name="allNinetyFiveLineTime">
<xsl:call-template name="line">
<xsl:with-param name="nodes" select="/testResults/*/@t" />
<xsl:with-param name="position" select="ceiling($allCount * 0.95)" />
</xsl:call-template>
</xsl:variable>
<xsl:variable name="allNinetyNineLineTime">
<xsl:call-template name="line">
<xsl:with-param name="nodes" select="/testResults/*/@t" />
<xsl:with-param name="position" select="ceiling($allCount * 0.99)" />
</xsl:call-template>
</xsl:variable>
请问两者为什么会不一致？求教！！！！
http://jmeter.apache.org/usermanual/glossary.html
https://en.wikipedia.org/wiki/Median
那这个 Median 的地方你改成 floor($allCount * 0.5+1)，奇数表示取中间数，偶数还是取偏小的那边的数
这个还真没注意到咧
—— 来自 TesterHome 官方 安卓客户端
计算方法有误吧，Jmeter 90% 水平线是升序排序后取的 90% 处的值
看样子你这个是降序排序了。。。
有没有公式源码，拿出来看看就知道了
对
arrow
回复
arrow
回复
我在帖子后方写了，allMedianLineTime，allNinetyLineTime····几个的计算方式，按理应该 allNinetyLineTime，allNinetyFiveLineTime，allNinetyNineLineTime 计算方式与 allMedianLineTime 一样，只是取值的位置不一样而已，为什么 allMedianLineTime 是对的，90%，95%，99% 就是不对
2 楼说的对的吧， 要看"line"模板帖子里没有，验证下可以把 0.9->0.1,0.95->0,05 试试是不是就一样了...allMedianLineTime 一样是正好 0.5 在中间，升降序没影响了
对
北溟
回复
北溟
回复
<xsl:template name="line">
<xsl:param name="nodes" select="/.." />
<xsl:param name="position" select="/.." />
<xsl:choose>
<xsl:when test="not($nodes)">NaN</xsl:when>
<xsl:otherwise>
<xsl:for-each select="$nodes">
<xsl:sort data-type="number" order="descending" />
<xsl:if test="position() = $position">
<xsl:value-of select="number(.)" />
</xsl:if>
</xsl:for-each>
</xsl:otherwise>
</xsl:choose>
</xsl:template>
这是 line,请大神指点，我将 0.9->0.1,0.95->0,05 类似于这样改了，其对应值改为了 0.9->0.15 0.95->0.1 0.99->0.01 这样 90%，95%，99% 值才对上，但运行结果后，当 Sample 为偶数的时候， jmeter-results-detail-report_21.xsl 输出 html 聚合报告结果中的 median 取的值就不对了
<xsl:sort data-type="number" order="descending" /> --> ascending
另外可能还是会对不上，计算位置的原因
ceiling(19*0.9)=18，以 90%line 为例看聚合报告里是应该是顺序的第 17 个，考虑把帖子里的 ceiling 函数换成 round 函数，四舍五入的
<xsl:with-param name="position" select="round($allCount * 0.9)" />
对
北溟
回复
北溟
回复
大神，是真的不行，之前我就试过了，结果依然和我说的结果一样·············
<?xml version="1.0"?>
<xsl:stylesheet xmlns:xsl="http://www.w3.org/1999/XSL/Transform" version="1.0">
<!--
Licensed to the Apache Software Foundation (ASF) under one or more
contributor license agreements. See the NOTICE file distributed with
this work for additional information regarding copyright ownership.
The ASF licenses this file to You under the Apache License, Version 2.0
(the "License"); you may not use this file except in compliance with
the License. You may obtain a copy of the License at
http://www.apache.org/licenses/LICENSE-2.0
Unless required by applicable law or agreed to in writing, software
distributed under the License is distributed on an "AS IS" BASIS,
WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
See the License for the specific language governing permissions and
limitations under the License.
-->
<!--
Stylesheet for processing 2.1 output format test result files
To uses this directly in a browser, add the following to the JTL file as line 2:
<?xml-stylesheet type="text/xsl" href="../extras/jmeter-results-detail-report_21.xsl"?>
and you can then view the JTL in a browser
-->
<xsl:output method="html" indent="yes" encoding="UTF-8" doctype-public="-//W3C//DTD HTML 4.01 Transitional//EN" />
<!-- Defined parameters (overrideable) -->
<xsl:param name="showData" select="'n'"/>
<xsl:param name="titleReport" select="'Load Test Results'"/>
<!-- <xsl:param name="dateReport" select="'date not defined'"/> -->
<xsl:template match="testResults">
<html>
<head>
<title><xsl:value-of select="$titleReport" /></title>
<style type="text/css">
body { font:normal 68% verdana,arial,helvetica; color:#000000; }
table tr td, table tr th { font-size: 68%; }
table.details tr th { color: #ffffff; font-weight: bold; text-align:center; background:#2674a6; white-space: pre-wrap; }
table.details tr td { background:#eeeee0; white-space: pre-wrap; }
h1 { margin: 0px 0px 5px; font: 165% verdana,arial,helvetica }
h2 { margin-top: 1em; margin-bottom: 0.5em; font: bold 125% verdana,arial,helvetica }
h3 { margin-bottom: 0.5em; font: bold 115% verdana,arial,helvetica }
.Failure { font-weight:bold; color:red; }
img { border-width: 0px; }
.expand_link { position: absolute; right: 0px; width: 27px; top: 1px; height: 27px; }
.page_details { display: none; }
.page_details_expanded { display: block; display/* hide this definition from IE5/6 */: table-row; }
.key { min-width: 108px; width: 15%; }
.detail, #tdetail { display: none; }
</style>
<script language="JavaScript"><![CDATA[
function toggle_details(details_id) {
var objImg = document.getElementById(details_id+"_image");
var objTable = document.getElementById(details_id);
if(objImg.alt == "collapse") {
objImg.alt = "expand";
objTable.className = "page_details_expanded";
} else {
objImg.alt = "collapse";
objTable.className = "page_details";
var arrTable = document.getElementsByClassName("detail");
for (var i=0; i<arrTable.length; i++) {
arrTable[i].style.display = "none";
}
}
};
function toggle_detail(detail_id) {
var objTitle = document.getElementById("tdetail");
var arrTable = document.getElementsByClassName("detail");
for (var i=0; i<arrTable.length; i++) {
var table = arrTable[i];
if (table.id != detail_id) {
table.style.display = "none";
} else {
if (table.style.display == "none" || table.style.display == "") {
table.style.display = "table";
objTitle.style.display = "block";
} else {
table.style.display = "none";
objTitle.style.display = "none";
}
}
}
};
]]></script>
</head>
<body>
<xsl:call-template name="pageHeader" />
<xsl:call-template name="summary" />
<hr size="1" width="95%" align="center" />
<xsl:call-template name="pagelist" />
<hr size="1" width="95%" align="center" />
<xsl:call-template name="detail" />
</body>
</html>
</xsl:template>
<xsl:template name="pageHeader">
<h1><xsl:value-of select="$titleReport" /></h1>
<!-- <table width="100%">
<tr>
<td align="left">Date report: <xsl:value-of select="$dateReport" /></td>
<td align="right">Designed for use with <a href="http://jmeter.apache.org/">JMeter</a> and <a href="http://ant.apache.org">Ant</a>.</td>
</tr>
</table> -->
<hr size="1" />
</xsl:template>
<xsl:template name="summary">
<h2>Summary</h2>
<table align="center" class="details" border="0" cellpadding="5" cellspacing="2" width="95%">
<tr valign="top">
<th># Samples</th>
<th>Failures</th>
<th>Success Rate</th>
<th>Average Time</th>
<th>Min Time</th>
<th>Max Time</th>
<th>Median</th>
<th>90% Line</th>
<th>95% Line</th>
<th>99% Line</th>
<th>QPS</th>
<th>KB/Sec</th>
</tr>
<tr valign="top">
<xsl:variable name="allCount" select="count(/testResults/*)" />
<xsl:variable name="allFailureCount" select="count(/testResults/*[attribute::s='false'])" />
<xsl:variable name="allSuccessCount" select="count(/testResults/*[attribute::s='true'])" />
<xsl:variable name="allSuccessPercent" select="$allSuccessCount div $allCount" />
<xsl:variable name="allTotalTime" select="sum(/testResults/*/@t)" />
<xsl:variable name="allAverageTime" select="$allTotalTime div $allCount" />
<xsl:variable name="allMinTime">
<xsl:call-template name="min">
<xsl:with-param name="nodes" select="/testResults/*/@t" />
</xsl:call-template>
</xsl:variable>
<xsl:variable name="allMaxTime">
<xsl:call-template name="max">
<xsl:with-param name="nodes" select="/testResults/*/@t" />
</xsl:call-template>
</xsl:variable>
<xsl:variable name="allMedianLineTime">
<xsl:call-template name="line">
<xsl:with-param name="nodes" select="/testResults/*/@t" />
<xsl:with-param name="position" select="ceiling($allCount * 0.5)" />
</xsl:call-template>
</xsl:variable>
<xsl:variable name="allNinetyLineTime">
<xsl:call-template name="line">
<xsl:with-param name="nodes" select="/testResults/*/@t" />
<xsl:with-param name="position" select="ceiling($allCount * 0.9)" />
</xsl:call-template>
</xsl:variable>
<xsl:variable name="allNinetyFiveLineTime">
<xsl:call-template name="line">
<xsl:with-param name="nodes" select="/testResults/*/@t" />
<xsl:with-param name="position" select="ceiling($allCount * 0.95)" />
</xsl:call-template>
</xsl:variable>
<xsl:variable name="allNinetyNineLineTime">
<xsl:call-template name="line">
<xsl:with-param name="nodes" select="/testResults/*/@t" />
<xsl:with-param name="position" select="ceiling($allCount * 0.99)" />
</xsl:call-template>
</xsl:variable>
<xsl:variable name="allEndTime">
<xsl:for-each select="/testResults/*/@ts">
<xsl:sort data-type="number" order="descending" />
<xsl:if test="position() = 1">
<xsl:value-of select="number(.)+number(../@t)" />
</xsl:if>
</xsl:for-each>
</xsl:variable>
<xsl:variable name="allBeginTime">
<xsl:for-each select="/testResults/*/@ts">
<xsl:sort data-type="number" order="descending" />
<xsl:if test="position() = $allCount">
<xsl:value-of select="number(.)" />
</xsl:if>
</xsl:for-each>
</xsl:variable>
<xsl:variable name="allNodeThroughput" select="$allCount div (number($allEndTime)-number($allBeginTime)) * 1000" />
<xsl:variable name="allNodeKB" select="(sum(/testResults/*/@by) div 1024) div (number($allEndTime)-number($allBeginTime)) * 1000" />
<xsl:attribute name="class">
<xsl:choose>
<xsl:when test="$allFailureCount > 0">Failure</xsl:when>
</xsl:choose>
</xsl:attribute>
<td align="center">
<xsl:value-of select="$allCount" />
</td>
<td align="center">
<xsl:value-of select="$allFailureCount" />
</td>
<td align="center">
<xsl:call-template name="display-percent">
<xsl:with-param name="value" select="$allSuccessPercent" />
</xsl:call-template>
</td>
<td align="center">
<xsl:call-template name="display-time">
<xsl:with-param name="value" select="$allAverageTime" />
</xsl:call-template>
</td>
<td align="center">
<xsl:call-template name="display-time">
<xsl:with-param name="value" select="$allMinTime" />
</xsl:call-template>
</td>
<td align="center">
<xsl:call-template name="display-time">
<xsl:with-param name="value" select="$allMaxTime" />
</xsl:call-template>
</td>
<td align="center">
<xsl:call-template name="display-time">
<xsl:with-param name="value" select="$allMedianLineTime" />
</xsl:call-template>
</td>
<td align="center">
<xsl:call-template name="display-time">
<xsl:with-param name="value" select="$allNinetyLineTime" />
</xsl:call-template>
</td>
<td align="center">
<xsl:call-template name="display-time">
<xsl:with-param name="value" select="$allNinetyFiveLineTime" />
</xsl:call-template>
</td>
<td align="center">
<xsl:call-template name="display-time">
<xsl:with-param name="value" select="$allNinetyNineLineTime" />
</xsl:call-template>
</td>
<td align="center">
<xsl:call-template name="display-persecond">
<xsl:with-param name="value" select="$allNodeThroughput" />
</xsl:call-template>
</td>
<td align="center">
<xsl:call-template name="display-decimal">
<xsl:with-param name="value" select="$allNodeKB" />
</xsl:call-template>
</td>
</tr>
</table>
</xsl:template>
<xsl:template name="pagelist">
<h2>Pages</h2>
<table align="center" class="details" border="0" cellpadding="5" cellspacing="2" width="95%">
<tr valign="top">
<th>URL</th>
<th># Samples</th>
<th>Failures</th>
<th>Success Rate</th>
<th>Average Time</th>
<th>Min Time</th>
<th>Max Time</th>
<th>Median</th>
<th>90% Line</th>
<th>95% Line</th>
<th>99% Line</th>
<th>QPS</th>
<th>KB/Sec</th>
<th></th>
</tr>
<xsl:for-each select="/testResults/*[not(@lb = preceding::*/@lb)]">
<xsl:variable name="label" select="@lb" />
<xsl:variable name="count" select="count(../*[@lb = current()/@lb])" />
<xsl:variable name="failureCount" select="count(../*[@lb = current()/@lb][attribute::s='false'])" />
<xsl:variable name="successCount" select="count(../*[@lb = current()/@lb][attribute::s='true'])" />
<xsl:variable name="successPercent" select="$successCount div $count" />
<xsl:variable name="totalTime" select="sum(../*[@lb = current()/@lb]/@t)" />
<xsl:variable name="averageTime" select="$totalTime div $count" />
<xsl:variable name="minTime">
<xsl:call-template name="min">
<xsl:with-param name="nodes" select="../*[@lb = current()/@lb]/@t" />
</xsl:call-template>
</xsl:variable>
<xsl:variable name="maxTime">
<xsl:call-template name="max">
<xsl:with-param name="nodes" select="../*[@lb = current()/@lb]/@t" />
</xsl:call-template>
</xsl:variable>
<xsl:variable name="medianLineTime">
<xsl:call-template name="line">
<xsl:with-param name="nodes" select="../*[@lb = current()/@lb]/@t" />
<xsl:with-param name="position" select="ceiling($count * 0.5)" />
</xsl:call-template>
</xsl:variable>
<xsl:variable name="ninetyLineTime">
<xsl:call-template name="line">
<xsl:with-param name="nodes" select="../*[@lb = current()/@lb]/@t" />
<xsl:with-param name="position" select="ceiling($count * 0.9)" />
</xsl:call-template>
</xsl:variable>
<xsl:variable name="ninetyFiveLineTime">
<xsl:call-template name="line">
<xsl:with-param name="nodes" select="../*[@lb = current()/@lb]/@t" />
<xsl:with-param name="position" select="ceiling($count * 0.95)" />
</xsl:call-template>
</xsl:variable>
<xsl:variable name="ninetyNineLineTime">
<xsl:call-template name="line">
<xsl:with-param name="nodes" select="../*[@lb = current()/@lb]/@t" />
<xsl:with-param name="position" select="ceiling($count * 0.99)" />
</xsl:call-template>
</xsl:variable>
<xsl:variable name="endTime">
<xsl:for-each select="../*[@lb = current()/@lb]/@ts">
<xsl:sort data-type="number" order="descending" />
<xsl:if test="position() = 1">
<xsl:value-of select="number(.)+number(../@t)" />
</xsl:if>
</xsl:for-each>
</xsl:variable>
<xsl:variable name="beginTime">
<xsl:for-each select="../*[@lb = current()/@lb]/@ts">
<xsl:sort data-type="number" order="descending" />
<xsl:if test="position() = $count">
<xsl:value-of select="number(.)" />
</xsl:if>
</xsl:for-each>
</xsl:variable>
<xsl:variable name="nodeThroughput" select="$count div (number($endTime)-number($beginTime)) * 1000" />
<xsl:variable name="nodeKB" select="(sum(../*[@lb = current()/@lb]/@by) div 1024) div (number($endTime)-number($beginTime)) * 1000" />
<tr valign="top">
<xsl:attribute name="class">
<xsl:choose>
<xsl:when test="$failureCount > 0">Failure</xsl:when>
</xsl:choose>
</xsl:attribute>
<td>
<xsl:value-of select="$label" />
</td>
<td align="center">
<xsl:value-of select="$count" />
</td>
<td align="center">
<xsl:value-of select="$failureCount" />
</td>
<td align="center">
<xsl:call-template name="display-percent">
<xsl:with-param name="value" select="$successPercent" />
</xsl:call-template>
</td>
<td align="center">
<xsl:call-template name="display-time">
<xsl:with-param name="value" select="$averageTime" />
</xsl:call-template>
</td>
<td align="center">
<xsl:call-template name="display-time">
<xsl:with-param name="value" select="$minTime" />
</xsl:call-template>
</td>
<td align="center">
<xsl:call-template name="display-time">
<xsl:with-param name="value" select="$maxTime" />
</xsl:call-template>
</td>
<td align="center">
<xsl:call-template name="display-time">
<xsl:with-param name="value" select="$medianLineTime" />
</xsl:call-template>
</td>
<td align="center">
<xsl:call-template name="display-time">
<xsl:with-param name="value" select="$ninetyLineTime" />
</xsl:call-template>
</td>
<td align="center">
<xsl:call-template name="display-time">
<xsl:with-param name="value" select="$ninetyFiveLineTime" />
</xsl:call-template>
</td>
<td align="center">
<xsl:call-template name="display-time">
<xsl:with-param name="value" select="$ninetyNineLineTime" />
</xsl:call-template>
</td>
<td align="center">
<xsl:call-template name="display-persecond">
<xsl:with-param name="value" select="$nodeThroughput" />
</xsl:call-template>
</td>
<td align="center">
<xsl:call-template name="display-decimal">
<xsl:with-param name="value" select="$nodeKB" />
</xsl:call-template>
</td>
<td align="center">
<a href="">
<xsl:attribute name="href"><xsl:text/>javascript:toggle_details('page_details_<xsl:value-of select="position()" />')</xsl:attribute>
</a>
</td>
</tr>
<tr class="page_details">
<xsl:attribute name="id"><xsl:text/>page_details_<xsl:value-of select="position()" /></xsl:attribute>
<td colspan="14" bgcolor="#FF0000">
<div align="center">
<b>Details for Page "<xsl:value-of select="$label" />"</b>
<table bordercolor="#000000" bgcolor="#2674A6" border="0" cellpadding="1" cellspacing="1" width="95%">
<tr>
<th>Thread</th>
<th>Iteration</th>
<th>Time</th>
<th>Bytes</th>
<th>Success</th>
</tr>
<xsl:for-each select="../*[@lb = $label and @tn != $label]">
<tr>
<td align="center">
<a><xsl:attribute name="href"><xsl:text/>javascript:toggle_detail('<xsl:text/><xsl:value-of select="@lb" />_detail_<xsl:value-of select="position()" />')</xsl:attribute>
<xsl:value-of select="@tn" />
</a>
</td>
<td align="center"><xsl:value-of select="position()" /></td>
<td align="center"><xsl:value-of select="format-number(@t, '0 ms')" /></td>
<!-- TODO allow for missing bytes field -->
<td align="center"><xsl:value-of select="@by" /></td>
<td align="center"><xsl:value-of select="@s" /></td>
</tr>
</xsl:for-each>
</table>
</div>
</td>
</tr>
</xsl:for-each>
</table>
</xsl:template>
<xsl:template name="detail">
<h2 id="tdetail">Details</h2>
<xsl:for-each select="/testResults/*[not(@lb = preceding::*/@lb)]">
<xsl:for-each select="/testResults/*[@lb = current()/@lb]">
<table align="center" class="details detail" border="0" cellpadding="5" cellspacing="2" width="95%">
<xsl:attribute name="id"><xsl:text/><xsl:value-of select="@lb" />_detail_<xsl:value-of select="position()" /></xsl:attribute>
<tr valign="top"><th colspan="2"><xsl:value-of select="@lb" /><xsl:text> # </xsl:text><xsl:value-of select="@tn"/></th></tr>
<tr><td class="key">Time</td><td><xsl:call-template name="display-time"><xsl:with-param name="value" select="@t" /></xsl:call-template></td></tr>
<tr><td class="key">Latency</td><td><xsl:call-template name="display-time"><xsl:with-param name="value" select="@lt"/></xsl:call-template></td></tr>
<tr><td class="key">Bytes</td><td><xsl:value-of select="@by"/></td></tr>
<tr><td class="key">Sample Count</td><td><xsl:value-of select="@sc"/></td></tr>
<tr><td class="key">Error Count</td><td><xsl:value-of select="@ec"/></td></tr>
<tr><td class="key">Response Code</td><td><xsl:value-of select="@rc"/></td></tr>
<tr><td class="key">Response Message</td><td><xsl:value-of select="@rm"/></td></tr>
<tr><td class="key">Failure Message</td><td><xsl:value-of select="assertionResult/failureMessage"/></td></tr>
<tr><td class="key">Method/Url</td><td><xsl:value-of select="method"/><xsl:text> </xsl:text><xsl:value-of select="java.net.URL"/></td></tr>
<tr><td class="key">Query String</td><td><xsl:value-of select="queryString"/></td></tr>
<tr><td class="key">Cookies</td><td><xsl:value-of select="cookies"/></td></tr>
<tr><td class="key">Request Headers</td><td><xsl:value-of select="requestHeader"/></td></tr>
<tr><td class="key">Response Headers</td><td><xsl:value-of select="responseHeader"/></td></tr>
<tr><td class="key">Response Data</td><td><xsl:value-of select="responseData"/></td></tr>
<tr><td class="key">Response File</td><td><xsl:value-of select="responseFile"/></td></tr>
</table>
</xsl:for-each>
</xsl:for-each>
</xsl:template>
<xsl:template name="min">
<xsl:param name="nodes" select="/.." />
<xsl:choose>
<xsl:when test="not($nodes)">NaN</xsl:when>
<xsl:otherwise>
<xsl:for-each select="$nodes">
<xsl:sort data-type="number" />
<xsl:if test="position() = 1">
<xsl:value-of select="number(.)" />
</xsl:if>
</xsl:for-each>
</xsl:otherwise>
</xsl:choose>
</xsl:template>
<xsl:template name="max">
<xsl:param name="nodes" select="/.." />
<xsl:choose>
<xsl:when test="not($nodes)">NaN</xsl:when>
<xsl:otherwise>
<xsl:for-each select="$nodes">
<xsl:sort data-type="number" order="descending" />
<xsl:if test="position() = 1">
<xsl:value-of select="number(.)" />
</xsl:if>
</xsl:for-each>
</xsl:otherwise>
</xsl:choose>
</xsl:template>
<xsl:template name="line">
<xsl:param name="nodes" select="/.." />
<xsl:param name="position" select="/.." />
<xsl:choose>
<xsl:when test="not($nodes)">NaN</xsl:when>
<xsl:otherwise>
<xsl:for-each select="$nodes">
<xsl:sort data-type="number" order="descending" />
<xsl:if test="position() = $position">
<xsl:value-of select="number(.)" />
</xsl:if>
</xsl:for-each>
</xsl:otherwise>
</xsl:choose>
</xsl:template>
<xsl:template name="display-percent">
<xsl:param name="value" />
<xsl:value-of select="format-number($value,'0.00%')" />
</xsl:template>
<xsl:template name="display-time">
<xsl:param name="value" />
<xsl:value-of select="format-number($value,'0 ms')" />
</xsl:template>
<xsl:template name="display-persecond">
<xsl:param name="value" />
<xsl:value-of select="format-number($value, '0.00 /s')" />
</xsl:template>
<xsl:template name="display-decimal">
<xsl:param name="value" />
<xsl:value-of select="format-number($value, '0.00')" />
</xsl:template>
</xsl:stylesheet>
以上是整个 jmeter-results-detail-report_21.xsl 文件的内容！有空烦请看看
你确定是改的以下地方吗，157~175 之间的 ceiing 改成 round，以及 513 行的改成 order="ascending"
我这里试了多次一般都对的上欸，不过是发现还有个问题数量是 15 的时候 90%，13.5 四舍五入应该取第 14 个但是聚合报告取的是 13 个；但其他又比较符合四舍五入的，所以如果反着看用剔除可能更准确，15 的时候 10% 是 1.5，它也正好符合五入的，剔除 2 个，第三个就是我们要的值符合
这样的话你 513 行还是不变用 descending 吧，157~175 之间的改成（注意 4 个都改）select="round($allCount * 0.1+1)，即 90%line 理解为剔除 10%（四舍五入）后的下一个
对
北溟
回复
北溟
回复
谢谢大神的指导，现在 90%，95%，99% 这个 3 个值是能对应上了，修改后的如下，但是 Median 的值当 sample 为奇数时候用 ceiling 或者 round 都是对的，但 sample 为偶数的时候，不管是用 ceiling 还是 round ，和聚合报取的值不一样，取的是聚合报告值的下一个值
<xsl:variable name="allMedianLineTime">
<xsl:call-template name="line">
<xsl:with-param name="nodes" select="/testResults/*/@t" />
<xsl:with-param name="position" select="ceiling($allCount * 0.5)" />
</xsl:call-template>
</xsl:variable>
<xsl:variable name="allNinetyLineTime">
<xsl:call-template name="line">
<xsl:with-param name="nodes" select="/testResults/*/@t" />
<xsl:with-param name="position" select="round($allCount * 0.1+1)" />
</xsl:call-template>
</xsl:variable>
<xsl:variable name="allNinetyFiveLineTime">
<xsl:call-template name="line">
<xsl:with-param name="nodes" select="/testResults/*/@t" />
<xsl:with-param name="position" select="round($allCount * 0.1)" />
</xsl:call-template>
</xsl:variable>
<xsl:variable name="allNinetyNineLineTime">
<xsl:call-template name="line">
<xsl:with-param name="nodes" select="/testResults/*/@t" />
<xsl:with-param name="position" select="ceiling($allCount * 0.01)" />
</xsl:call-template>
4 个都用 round,且都 +1,你只改了中间 2 个
第三个也错了是 95% 是 0.05，round($allCount * 0.05+1) ，50% 是 0.5，90 是 0.1，95% 是 0.05,99% 是 0.01
对
北溟
回复
北溟
回复
谢谢，如您所说，90%，95%，99%，这 3 个值现在正常了，但当 sample 为奇数时候，Median 取值不一样了，round($allCount * 0.5+1)，我的 sample 值奇数为 19，偶数为 18
http://jmeter.apache.org/usermanual/glossary.html
https://en.wikipedia.org/wiki/Median
那这个 Median 的地方你改成 floor($allCount * 0.5+1)，奇数表示取中间数，偶数还是取偏小的那边的数
楼主，您好
请问你的 jmeter-results-detail-report_21.xsl 是自己改写过的嘛？
默认是没有 90%Line，95%Line，99%Line 和 QPS 的吧？
谢谢啦
